Before You Begin Installing Calculating Current Draw and Standby Battery
3.7.2 Current Draw Worksheet for Fike IDP SLC Devices
Use Table 3.3 to determine current requirements during alarm/battery standby operation when SLC devices are installed. You can install up
to 75 IDP detectors and 75 IDP modules
1
.
Device # of Devices Current per Device
Standby
Current
Alarm Current
For each device use this formula: This column X This column = Current per number of devices.
Fire Panel (Current draw from battery) 1 Standby: 165 mA 165 mA
Alarm: 310 mA 310 mA
Addressable SLC Detectors
FIK-2351 SLC Standby: 200µA mA
Alarm: 4.5mA mA
FIK-2351R SLC Standby: 200µA mA
Alarm: 4.5mA mA
FIK-2351T SLC Standby: 200µA mA
Alarm: 4.5mA mA
FIK-5351 SLC Standby: 200µA mA
Alarm: 4.5mA mA
FIK-5351R SLC Standby: 200µA mA
Alarm: 4.5mA mA
FIK-5351H SLC Standby: 200µA mA
Alarm: 4.5mA mA
DNR
5
(non-Relay) None, included with FIK-2351R
6
DNR
6
(with Relay) None, included with FIK-2351R & FIK-M500R
7
Addressable SLC Modules
FIK-M500M Standby/Alarm 0.375 mA mA mA
FIK-M501M mA mA
FIK-PULL-SA/FIK-PULL-DA
FIK-M500DM Standby/Alarm: 0.75mA mA mA
FIK-IM-10 Standby/Alarm: 3.5mA mA mA
FIK-M500S SLC Standby: 0.375mA
Alarm: 0.375mA
mA
mA
Aux Pwr Standby: 1.7mA mA
Alarm: 7mA mA
FIK-SC-6 SLC Standby: 2.25mA
Alarm: 2.25mA
mA
mA
Aux Pwr Standby: 8mA mA
Alarm: 20mA mA
FIK-M500R Standby/Alarm: .255mA mA mA
FIK-CR-6 Standby/Alarm: 1.45mA mA mA
FIK-M500MR-2 Standby: 1.3mA mA
Alarm: 24mA mA
FIK-M502M Aux Pwr Standby: 12mA mA mA
Alarm: 90mA mA mA
SLC Standby/Alarm: .27mA mA mA
FIK-CZ-6 Aux Pwr Standby: 50mA mA mA
Alarm: 270mA mA mA
SLC Standby/Alarm: 2mA mA mA
SLC Accessories
B200S-WH / -IV Intelligent sounder base Aux Pwr Standby: .5mA mA
Alarm: (high vol) 35mA mA
SLC Standby .3mA mA
B200S-LF-WH / -IV Low Frequency sounder base Aux Pwr Standby .55mA mA
Alarm (high vol) 140mA mA
SLC Standby .30mA mA
B224RB-WH / -IV Relay Base Standby/Alarm: .5mA mA mA
SLC Isolator Devices
FIK-M500X (100 max.) Standby/Alarm: .45mA mA mA
Color Guide: -IV = Ivory color, -BL = Black, -WH = White, -WHITE-White
Table 3.3 Current Calculation Worksheet for Fike IDP Devices
