FCP-75 Manual — P/N LS10147-003FK-E:A 3/17/2021 65
Section 7: Fike IDP and SWIFT
SLC Device Installation
7.1 List of Fike IDP SLC Devices
The following Fike IDP SLC devices can be used with the control panel. See the device installation instructions for more information (pack-
aged with the device).
7.2 SWIFT Wireless SLC Devices
The FIK-W-WGI Wireless Gateway acts as a bridge between a group of wireless fire devices and a SLC loop on the FCP-75. It is powered
by the SLC loop or by a regulated, external 24VDC UL-listed power supply. Available wireless devices include a photo detector, a
photo/heat detector, a fixed-temperature heat detector, a rate-of-rise detector, and a monitor module. For updated details about wireless
devices, system setup and operation see the SWIFT Smart Wireless Integrated Fire Technology Manual # LS10036-000FK-E for more infor-
mation.
7.3 Maximum Number of Devices
The FCP-75 supports IDP or SWIFT devices on one FCP-75 system. The maximum number of devices per system varies depending on
device protocol Device support is as follows:
• IDP Devices–An FCP-75 system can support a total of 75 IDP detectors and 75 IDP modules. For a maximum of 150 points.
or
• SWIFT Wireless Devices–A SWIFT Gateway system supports up to 50 devices: 1 SWIFT Gateway and up to 49 (in any combination)
wireless detectors and monitor modules. Multiple Gateways can be used. See the SWIFT manual P/N LS10036-000FK-E for more
information.
CAUTION: TO AVOID THE RISK OF ELECTRICAL SHOCK AND DAMAGE TO THE UNIT, POWER SHOULD BE OFF AT
THE CONTROL PANEL WHILE INSTALLING OR SERVICING.
Part Numbers Model Name/Description Install Sheet PN
FIK-2351 Photoelectric smoke detector I56-6632
FIK-2351T Photoelectric smoke detector with thermal (135°F)
I56-6633
FIK-2351R Photoelectric replacement smoke detector with remote test capability in DNR I56-6634
DNR/DNRW Duct smoke detector housing. Non-relay (photo sold separately) I56-3051
FIK-5351 Fixed temperature thermal detector (135°F)
I56-6635FIK-5351R Rate-of-rise thermal detector with 135° fixed temperature
FIK-5351H Fixed high temperature thermal detector (190°F)
FIK-FC351 Multi-criteria fire CO detector I56-6637
FIK-2351TIR Multi-criteria PTIR detector I56-6639
FIK-PULL-SA Addressable single action pull station I56-6959
FIK-PULL-DA Addressable dual action pull station I56-6958
FIK-M500X Fault isolator module I56-6897
ISO-6 Six Fault isolator module I56-4096
FIK-M500M Monitor module I56-6671
FIK-M501M Mini monitor module I56-6673
FIK-M500DM Dual input monitor module I56-6672
FIK-IM-10 10 input monitor module I56-6893
FIK-M500R Relay module I56-6674
FIK-CR-6 Six circuit relay module I56-6894
FIK-M500MR-2 Multi module with 2 relay outputs & 2 monitor inputs I56-6895
FIK-M502M Zone interface module I56-6676
FIK-CZ-6 Six zone interface module I56-6896
FIK-M500S Supervised control module I56-6675
FIK-SC-6 Six circuit supervised control module I56-6891
FIK-W-WGI Wireless gateway module LS10036-000FK-E
B200S-WH
/ IV Intelligent Sounder base. I56-3387
B200S-LF-WH / IV Low Frequency Sounder Base I56-4151
B300-6/ -IV 6” Plug-in Detector Base I56-6566
B224RB-WH / IV 6" relay base I56-3737
B501-BL/-IV/-WHITE 4" Plug-in Detector Base I56-0357
Color Guide: -IV = Ivory color, -BL = Black, -WH = White, -WHITE-White
Table 7.3 Fike IDP SLC Devices
