Reporting SIA– FCP-75 Panel Communicator:
4. When Reporting-by-Point is enabled, the communicator uses a “pi” event to supersede the actual point event to report the module to
which the point is linked.
5. The Panel ID is not sent in the SIA Event Parameters.
For Example see Table 11.3:
11.3 SIA– FCP-75 Panel Communicator:
(Differences/additional features are underlined).
The Events are sent to the Central Station Receiver as a fixed length string:
The Event Format is:
EEPPMMZZZZ
Where the Event Format is defined as follows:
1. The Event field will contain 10 digits including the 2 digit Event Code (EE), 2 digit panel ID (PP), 2 digit Module Number (MM) and a
4 digit Event Parameter (ZZZZ).
2. Based on the actual Event Code, the Module Number or Event Parameter fields might not contain pertinent information. In that case the
field will contain zeros.
3. The account number is sent using an account block that is separate from the event block.
4. Multiple events can be sent within a single event block. Events are separated by a “/” character.
5. Event parameter can be a Zone, Point or Circuit Number.
6. “pi” modifier event is not used.
7. Panel can be set to report by either Point or Zone.
For examples, see Table 11.4.
Event
Report
Zone/
Point
Panel
ID
Module
Zone
ZZZZ
Point
ZZZZ
Fields Sent
SIA Event
Data
Fire Alarm-Zone Zone n/a n/a97 15 n/a EE-ZZ FA15
Fire Alarm-Zone Zone n/a n/a 05 n/a EE-Z FA5
Fire Alarm-Point Point n/a 01 n/a 123 EE-ZZ /EE-ZZZ pi01/FA123
Fire Alarm-Point Point n/a 33 n/a 203 EE-ZZ /EE-ZZZ pi11/FA203
Expander Trouble n/a n/a 11 n/a n/a EE-ZZ ET11
Auto Test n/a n/a n/a n/a n/a EE-Z RP0
Battery Trouble-Panel 32 n/a n/a 98 n/a n/a EE-ZZ YT98
Battery Trouble-Expander 18 n/a n/a 18 n/a n/a EE-ZZ YT18
SLC Loop Shorted n/a n/a 44 n/a n/a EE-ZZ ET44
Program Begin Panel ID=32 n/a n/a n/a n/a n/a EE-Z LB0
Program Begin Panel ID= 22 n/a n/a n/a n/a n/a EE-Z LB0
AC Power Loss - Panel 22 n/a n/a 98 n/a n/a EE-Z AT0
Fire Trouble Point n/a 97 n/a 200 EE-ZZ /EE-ZZZ pi97/FT200
Fire Trouble Zone n/a 97 01 n/a EE-Z FT1
Fire Trouble-NAC Point n/a 98 n/a NAC Circuit
7
EE-ZZ /EE-Z pi98/FT7
Z=Pt. #
Fire Trouble-NAC Zone n/a 98 n/a NAC Circuit
7
EE-ZZZ FT400
ZZZ=OPG#
Table 11.3 SIA: FCP-75 Panels - PI Modifier Reporting Examples
Code Event Code Description
EE
Event code (2 characters)
PP
Panel number (2 digits – Zero Filled) (valid range from 1 to 64)
MM
Module number (2 digits – Zero Filled) (valid range from 1 to 98, typically Module information)
ZZZZ
Event parameter (4 digits – Zero Filled
) (typically Point, Zone or Circuit information)
Event
Report
Zone/Point
Panel ID
PP
Module
MM
Zone
ZZZZ
Point
ZZZZ
Fields
Sent
SIA Event
Data
Fire Alarm-Zone Zone 32 n/a 15 n/a EE-PP-MM-ZZZZ FA32000015
Fire Alarm-Zone Zone 32 n/a 05 n/a EE-PP-MM-ZZZZ FA32000005
Fire Alarm-Point Point 32 01 n/a 123 EE-PP-MM-ZZZZ FA32010123
Fire Alarm-Point Point 21 33 n/a 203 EE-PP-MM-ZZZZ FA21330203
Table 11.4 SIA REPORTING EXAMPLES
