SIA– FCP-75 Panel Communicator: Reporting
FCP-75 Manual — P/N:LS10147-003FK-E:A 3/17/2021 121
Expander Trouble n/a 15 11 n/a n/a EE-PP-MM-ZZZZ ET15110000
Auto Test n/a 32 n/a n/a n/a EE-PP-MM-ZZZZ RP32000000
Battery Trouble-Panel 32 n/a 32 98 n/a n/a EE-PP-MM-ZZZZ YT32980000
Battery Trouble-Expander 18 n/a 32 18 n/a n/a EE-PP-MM-ZZZZ YT32180000
SLC Loop Shorted n/a 01 44 n/a n/a EE-PP-MM-ZZZZ ET01440000
Program Begin n/a 32 n/a n/a n/a EE-PP-MM-ZZZZ LB32000000
Program Begin n/a 22 n/a n/a n/a EE-PP-MM-ZZZZ LB22000000
AC Power Loss- Panel 22 n/a 22 98 n/a n/a EE-PP-MM-ZZZZ AT22980000MM = 00
Fire Trouble Point 22 97 n/a 200 EE-PP-MM-ZZZZ FT22970200
Fire Trouble Zone 22 97 1 n/a EE-PP-MM-ZZZZ FT22970001MM = 00
Fire Trouble-NAC Point 22 98 n/a NAC Circuit 7 EE-PP-MM-ZZZZ FT22980007ZZZZ=Pt. #
Fire Trouble-NAC Zone 22 98 n/a NAC Circuit 7 EE-PP-MM-ZZZZ FT22980007ZZZZ=OPG #
Table 11.4 SIA REPORTING EXAMPLES (Continued)
