134 FCP-75 Manual — P/N LS10147-003FK-E:A 3/17/2021
Compatible Devices Notification Appliances
Two-Wire Smoke Detectors
Table A.2 lists two-wire smoke detectors that are compatible with the fire control panel. The table is organized by manufacturer. The col-
umns show the number of detectors per loop that can be used..
Wheelock
(cont.)
RSSR-2475W
x
Strobe
RSSR-2475C
x
Strobe
RSSR-24110C
x
Strobe
RSSA-24110W
x
Strobe
RSSB-24110W
x
Strobe
RSSG-24110W
x
Strobe
RSSR-24110W
x
Strobe
RSSA-24MCC
x
Multi-Cd Strobe
RSSB-24MCC
x
Multi-Cd Strobe
RSSG-24MCC
x
Multi-Cd Strobe
RSSR-24MCC
x
Multi-Cd Strobe
RSSWPA-2475W
x
Strobe Weatherproof
RSSWPA-24MCCH
x
Strobe Weatherproof
RSSWPG-24MCCH
x
Strobe Weatherproof
RSSWPR-24MCCH
x
Strobe Weatherproof
RSSWP-2475W
x
Strobe Weatherproof
RSSWP-2475C
x
Strobe Weatherproof
RSSWP-24MCWH
x
Strobe Weatherproof
ZRS-MCWH
x
Strobe
ZRS-24MCC
x
Strobe
ZRS-24MCCH
x
Strobe
MB-G6-24
x
Motor Bell
MB-G10-24
x
Motor Bell
MB-G6-12
x
Motor Bell
MB-G10-12
x
Motor Bell
MIZ-24-R
x
Mini-Horn
MT-12/24-R
xx
Multitone Horn
MT4-12/2z
xx
Multitone Horn
ZRS-MCW
x
Strobe
MTWPR-24MCCH
xx
Multitone Horn Strobe
NH-12/24R
x
Horn
HSR
x
Horn/Strobe
HSW
x
Horn/Strobe
STR
x
Strobe
STW
x
Strobe
HNR
x
Horn
HNW
x
Horn
FCP-75
Identifier
24H
Operating Voltage Range
18.5–27.4 VDC
Manufacturer Model Audio Visual Type
Table A.1 Compatible Notification Appliances (Continued)
•
NOTE: The maximum number of smoke detectors per zone is determined by both the current draw and the impedance of the smoke detector.
If too many smoke detectors are used on any zone, false alarms could occur.
• Do not mix different models of detectors on any zone; false alarms could occur.
• Do not mix detectors of different models unless the system is specifically intended to be installed in that configuration.
• Control unit Smoke Reset Time must be programmed for a number greater than or equal to the maximum reset time of the smoke detector
