Fiori DB 460 - Replacing the Drum Reduction Gear Oil

137
5
MAINTENANCE
id.:
DB 460 REV. 00 02/01/2015
5.10.7 REPLACING THE DRUM REDUCTION GEAR OIL (fi g. 22)
CAUTION: Before proceeding, always read the safety regulations for the operations to be carried out
as set out in Chapter 3.
CAUTION: Do not pollute the environment. Keep used oils in special containers and send them to
companies specialised in storage and disposal of polluting and hazardous waste.
- Move the vehicle onto fl at ground, engage the parking brake, turn off the engine and remove the ignition
key.
- Work from underneath the vehicle to access the reduction gear.
- Unscrew the drain cap A and drain out all the oil into a prearranged container.
- Add the specifi ed oil through the fi ller cap B using a syringe.
- Screw the caps A and B back on.
22
A
B
