Fiori DB 460 - Battery Pins Contact; Battery Replace

151
5
MAINTENANCE
id.:
DB 460 REV. 00 02/01/2015
5.12.5 BATTERY PINS CONTACT
- Disconnect the battery by removing the key from the battery master switch and proceed as described above
to access the battery, remove the terminals and thoroughly clean their ends.
- Refi t the terminals and grease them with a layer of Vaseline grease.
- Refi t the battery into place and reconnect it by inserting the key in the battery master switch.
5.12.6 BATTERY REPLACE
CAUTION: Before proceeding, always read the safety regulations for the operations to be carried out
as set out in Chapter 3.
CAUTION: Before proceeding, always read the safety regulations for the operations to be carried out
as set out in Chapter 3.
CAUTION: For this operation contact an electrical repair shop and always replace the battery with one
of the same amperage.
CAUTION: Do not pollute the environment. Keep the old battery in a suitable container and send it to
companies specialised in storage and disposal of polluting and hazardous waste.
- Disconnect the battery by removing the key from the battery master switch.
- Proceed as described above to access the battery.
- Remove the terminals.
- Unscrew the retaining clip.
- Remove the battery from its seat and replace it.
- Refi t the battery following the removal operations in reverse order, and remember to grease the terminals
with Vaseline grease.
