OPERATION AND USE
id.:
DB 460 REV. 00 02/01/2015
4.2.2.d Maintenance schedule (fi g. 5)
In case the warning light (1) stays on, it means that it is almost time to do maintenance to the machine (the
warning light indicates this event about 20 hours before the deadline set by FIORI).
The preset service interval is every 500 hours. Therefore, the warning light will fl ash after 500, 1000, 1500,
2000, ... hours.
Once the vehicle has been serviced, the fl ashing warning light can be reset and the counter reset to start the
countdown to the next service.
To reset fl ashing, hold the reset button (E) on the driving post instrument panel pressed down for 20 seconds.
After 20 seconds the word “RESET” will appear on the display and the warning light (1) will come on. To reset
the counter, release the button and press it again for another 2 seconds.
After the 2 seconds the new service interval will appear on the display and after another 3 seconds the panel
returns to normal display.
If you cut the power by disconnecting the battery master switch or remove the key before the operation is
complete, or you do not carry out the sequence as described above, fl ashing will not be reset.
CAUTION: It may be reset only after the pre-set due date and not before.
Push the selector forward to engage forward gear.
Always return the selector to neutral position when the vehicle is stationary and parked.
Push the selector backward to engage reverse gear.
4.2.2.e - A - Forward/reverse gear selector (fi g. 6).
Flick the switch forward to use the normal driving functions. This function is enabled only with
the selector (A) forward to engage forward gear.
Flick the switch backward (tortoise) to maintain a constant low speed, useful to carry out
dangerous manoeuvres, precision manoeuvres in tight spaces and to drive downhill using the
engine brake.
4.2.2.f - B - Slow movement switch (fi g. 6).
6
A
B
F
D
E
G
H
C
