81
4
OPERATION AND USE
id.:
DB 460 REV. 00 02/01/2015
4.3.6 DRIVING POST PIVOTING (fi g. 18)
CAUTION: Turn the driving post with the vehicle stationary and stable.
This operation may be carried out while you are seated on the driver’s seat. Check that it is
locked into place after the operation.
The driving post must always face forward A during road transfer and backward B, turned 180° for the drum
loading phases.
Press the lever (1) to release the driving post, turn it in the desired direction and relock the lever (1).
If the driving post is not perfectly locked, dedicated microswitches (2) will not allow vehicle movement.
18
B
A
2
2
1
