OPERATION AND USE
id.:
DB 460 REV. 00 02/01/2015
CAUTION: Before starting the vehicle, adjust and lock the seat in the most suitable and comfortable
position, so that you can easily reach all the controls, and fasten the seatbelt.
Use the lever (1) to adjust the seat distance from the pedals and the lever (2) to adjust the springing hardness
(according to your weight). Use the knob (3) to adjust the seat height. .
16
3
2
1
4.3.4 ADJUSTING THE SEAT (fi g. 16)
4.3.5 ADJUSTING THE REAR-VIEW MIRROR (fi g. 17)
CAUTION: Operation to be carried out before starting the vehicle.
To adjust the fi eld of vision of the sideview mirror (1), turn it so that you can see the rear left-hand side of the
vehicle as shown in the fi gure.
delivery switching valve B in position 1 or 2 but not in the central position.
Finally, refi t the closing cap C.
17
1
