OPERATION AND USE
id.:
DB 460 REV. 00 02/01/2015
4.2.1.k - F - Water pumps control switch (fi g. 6).
Snap switch to turn on the four hazard warning lights.
4.2.1.l - G - Hazard light toggle switch (fi g. 6).
Snap switch to turn on the rear working lights.
4.2.1.m - H - Working light switch (fi g. 6).
This switch controls the operation of the vehicle water pump.
Follow the instructions below:
1st click - Pump on (warning light S1 on)
2nd click - Pump off (warning light S1 off).
