SAFETY PRECAUTIONS
id.:
DB 460 REV. 00 02/01/2015
A - REVERSING MICRO-SWITCHES (fi g.1)
When the driving post is in the loading or transfer position it determines the FORWARD AND REVERSE
movement according to the driving position of the operator in that precise moment.
When the pivoting driving post is turned in the working direction, high gear cannot be engaged even if the
SLOW/FAST switch is set to fast.
Moreover, the vehicle can only operate when the driving post is correctly positioned in the driving direction.
C - PARKING BRAKE BUTTON (fi g.1)
It lets you engage the parking brake with the engine running.
The vehicle is automatically braked when the engine is off with the key in the “0” position.
D - MECHANICAL ROTATION LOCK FOR PIVOTING DRIVING POST (fi g.1)
Allows locking the driving post in the two driving positions.
3.5 SAFETY DEVICES ON THE VEHICLE
CAUTION: To check proper functioning of the safety devices and the cleaning and replacement
intervals, refer to chapter 5.4 SCHEDULED MAINTENANCE TABLE
The vehicle is equipped with safety devices whose specifi c functions are described in the legend below:
B - SEAT BELTS (fi g.1)
Always fasten the seatbelt when operating the vehicle.
The seatbelt is essential as it holds you anchored on the seat in the event of the vehicle overturning.
Periodically check the integrity, cleanliness and fastening of the structure.
1
A
E
B
F
C
D
