14 SEBU8325-01
Product Information Section
Model Views
1104 Engine Model Views
g01351713
Illustration 10
Typical ex ample
(1) Pulley
(2) Alternator
(3) Front Lifting Eye
(4) Water O utlet
(5) Valve Mechanism Cov er
(6) Rear Lifting Eye
(7) Air Intake
(8) Secondary Fuel Filter
(9) Fuel Injection Pump
(10) Oil Filter
(11) Crankshaft Pulley
(12) Water Pump
