INTRODUCTION
1
A - VEHICLE SERIAL NUMBER
The serial number is punched on the bumper side, on the right-hand side of the machine (with respect to
the driving direction).
CAUTION: This number must always be provided whenever requesting assistance from the FIORI
After Sales Service Network. The serial number is also required to facilitate identifying the
machine in the event of theft.
B - VEHICLE AND MANUFACTURER’S DATA PLATE
The vehicle and Manufacturer’s data plate is found on the front right-hand bumper, as shown in the fi gure.
Please fi ll in the following data concerning your vehicle:
MODEL/TYPE ................................................................................................................... DB 460 / BF08H
SERIAL NUMBER .................................................................................•BF08H 0 0900• / •BF08H A 0900•
YEAR ............................................................................................................................................................
C - ENGINE DATA PLATE
The engine data plate is positioned on the power take-off side.
Write down your vehicle numbers in the space below for quick and easy reference:
MODEL No. ................................................................2612/2400 (1104A-44T) - 3058/2200 (1104D-44TA)
SERIAL NUMBER ........................................................................................................................................
D - AXLE DATA PLATE
The axle type and serial numbers are printed on the plate found on the axle central case.
Write down the information in the space below for quick reference:
FRONT AXLE TYPE ...................................................................................................... • 000 - 212 - A22 •
SERIAL NUMBER ...................................................................................................................... K ITA......
REAR AXLE TYPE .........................................................................................................• 357 - 212 - 465 •
SERIAL NUMBER ...................................................................................................................... K ITA......
E - TRANSMISSION DATA PLATE
The serial number and type are punched on the pump (1) and engine (2) plates.
Write down the information in the space below for quick reference:
1- PUMP MODEL .................................................................................................................... • A4VG56 •
SERIAL NUMBER ...................................................................................................................................
2- ENGINE MODEL ................................................................................................................. • A6VM80 •
SERIAL NUMBER ...................................................................................................................................
F - OPERATOR PROTECTION PLATE
The ROPS - FOPS operator’s protection plate is found inside the upper section of the structure.
