OPERATION AND USE
id.:
DB 460 REV. 00 02/01/2015
Indicates the three types of steering.
Indicates the selection for the drum rotation direction. With the pivoting
post turned towards the drum: if the drum turns anticlockwise, the concrete
is unloaded; if it turns clockwise the concrete is mixed.
Indicates the joystick positions for arm raising, bucket rotation and
hydraulic hatch closing/opening.
Indicates the lever positions for chute tilting.
Indicates the functions to run to directly fi ll the drum or the tanks with
water, with the warning to open the cap to avoid the tank from swelling.
Indicates the position of the hand accelerator that allows you to adjust the
engine rpm when the vehicle is stationary. The vehicle can only be moved
when the lever is in the initial position (0).
