Annex
30.10.12 Chapter 14: Annex - Page 157
14. Annex
14.1 Technical data
14.1.1 Technical data for iControl 2 control unit
Fig. 14.1.1-1: Technical data for iControl 2 control unit
14.1.2 Technical data for iControl2 remote control panel
Fig. 14.1.2-1: Technical data for iControl2 remote control panel
iControl 2 control unit
Supply voltage 12V-13.5V (12V automotive)
Current consumption, nominal 175 mA
Current consumption, stand-by 2.5 mA
Operating temperature -20°C to +85°C
Storage temperature -30°C*to +85°C
Current sensor Hall element max. 20A
max. tightening torque for connecting bolts 1.2 Nm
iControl 2 control unit
Supply voltage 12V-24V (12V or 24V automotive)
Current consumption, off 0 mA
Current consumption, stand-by - backlight brightness 9 45 mA
Current consumption, stand-by - backlight brightness 4 33 mA
Current consumption, stand-by - backlight brightness 0 25 mA
Operating temperature -20°C to +70°C
Storage temperature -30°C*to +80°C
