Installation Instructions
30.10.12 Kapitel/Chapter 6: Installation Instructions Seite/Page 83
Fig. 6.8.17-4: Installation diagram with special air separator
6.9 Radiator fan control / electronic fan control
To control the radiator fan, various controls/electronic controls can be chosen from the Fischer Panda delivery
program.
Note!:In the following the basic functions of the fan controls
are described. The original manual/ data sheet with
further informations of the fan control must be
respected.
6.10 Standard fan control for 1-phase and 3-phase generators.
In the standard kit, the generators will be equipped with a one step fan control.
2
7
6
1
4
5
3
3
1. Ventilation pipe
2. Coolant expansion tank
3. T-piece for coolant expabsion tank
4. Water-cooled pre-silencer
5. Exhaust output
6. Special air separartor
7. Radiator
