Fischer Panda 5000i PVK-U - Electronic Fan Control for Single Phase Fans Pxet6 Q_Ziehl Abegg; Preset for the Use with Fischer Panda Generators

Installation Instructions
Seite/Page 92 Kapitel/Chapter 6: Installation Instructions 30.10.12
6.15 Electronic fan control for single phase fans PXET6Q_Ziehl Abegg
The electronic fan control variety the fan rpm stepless.
6.15.1 Preset for the use with Fischer Panda generators
The Ziehl Abegg fan control is preset for the use with Fischer Panda generators. For the preset following data and
jumper settings are used.
Fig. 6.15-1: Preset
