Installation Instructions
Seite/Page 68 Kapitel/Chapter 6: Installation Instructions 30.10.12
6.6.2 How to connect two 12V batteries to a 24V battery bank
Fig. 6.6.2-1: Installation starter batteryThe starter batteries have to be connected in this order:
1. (+) cable of first battery
Fig. 6.6.2-2: Installation starter battery2. (-) cable of second battery
Fig. 6.6.2-3: Installation starter battery3. (+) cable of second battery
