The Panda Generator
Seite/Page 46 - Kaptitel/Chapter 4: The Panda Generator 30.10.12
4.3.6 Thermosensor/switches
Fig. 4.3.6-1: Thermosensor cylinderheadThermosensor engine
Fig. 4.3.6-2: Thermoswitch/sensorThermoswitch/Thermosensor pre silencer
At this point the cooling water has normal the highest temp.
1. Thermosensor
2. 82°C/77°C (Fan fast)
3. 75°C/70°C (Fan slow)
Fig. 4.3.6-3: ResistorResistor
01. The resistor is connected in row with the Thermo switch
75°C/70°C.
1
2
3
1
