Fischer Panda 5000i PVK-U - The Oil Circle; Operation Instructions - See Separate Control Panel Manual; Daily Routine Checks before Starting - See Icontrol Manual; Starting Generator - See Icontrol Manual

The Panda Generator
30.10.12 Kapitel/Chapter 4: The Panda Generator - Seite/Page 47
Fig. 4.3.6-4: Thermosensor windingWinding- Thermosensor
Another Thermosensor is build into the winding
4.3.7 The oil circle
Fig. 4.3.7-1: The oil circle
4.4 Operation Instructions - see separate control panel manual
4.4.1 Daily routine checks before starting - See iControl manual.
4.4.2 Starting Generator - See iControl manual.
4.4.3 Stopping the Generator - See iControl manual.
oil filler cap
engine
Kubota EA300
oil strainer
oil dipstick
oil
pressure
switch
oil drain hose
iControl electronic board
operator control
oil in
oil
out
