Installation Instructions
30.10.12 Kapitel/Chapter 6: Installation Instructions Seite/Page 73
Fig. 6.8.2-3: T-pieceT-piece
f.e. for connection of the external expansion tank.
representative picture
Fig. 6.8.2-4: Sensor connection piece
Sensor connection piece
representative picture
Fig. 6.8.2-5: Roof passage
Roof passage
single or double passage
representative picture
Fig. 6.8.2-6: External expansion tank
External expansion tank
representative picture
