Maintenance Instructions
22.3.11 Panda PMS 8.000 NE - 42 NE Manual.R05 - Kapitel/Chapter 6: Maintenance Instructions Seite/Page 113
6.9.2 Refilling oil
1. Remove the Allen screw M8 at the right side of the sensor cable.
2. Refill some oil by means of a small hopper or a syringe.
3. Now tighten the screw again and fasten it with 20 Nm.
6.9.3 Refiller-Set
An appropriate refiller set can be purchased at Fischer Panda.
The refiller set contains:
Oil: Shell Omala HD220.
Syringe plus hose
6.9.4 Screw plug
Fig. 6.9.4-1: Screw plug
ATTENTION:
The screw plug has a ventilation hole!
Do NOT replace it by a normal screw - this will cause oil loss!
