5.9.5 Installation with mini VCS mounted at the generator
Fig. 5.9.5-1: Installation with mini VCS mounted at the generator
All electrical safety installations have to be made on board.
5.9.6 Jump start at high starting current (Booster)
Additionally, the automatic start booster is located on the circuit control board. The starting current is increased by
connecting a second group of capacitors (C2), if the voltage drops below a pre-set voltage. The starting current can
be increased by 300% for a short period by combining both components voltage/speed control and ASB Start boo-
ster.
1
2
1. Generator 2. Distribution panel
