The Panda Generator
Seite/Page 52 Panda_6500_7mini_PMS_eng.R01 - Kapitel/Chapter 4: The Panda Generator 22.3.11
Fig. 4.3.5-4: Exhaust Output
Exhaust outlet
4.3.6 Components of Electrical System
Fig. 4.3.6-1: Battery cable (+)
Connection starter battery
1. Cable for starter battery (plus)
Connect the battery (+) directly to the starter solonoid
Fig. 4.3.6-2: Connections for starter battery
Connection starter battery
1. Cable for starter battery (minus)
Connect the battery (-) to the generator foot connnection
point.
1
1
