Maintenance Instructions
22.3.11 Panda PMS 8.000 NE - 42 NE Manual.R05 - Kapitel/Chapter 6: Maintenance Instructions Seite/Page 137
6.14.1 Replacement of the impeller
Fig. 6.14.1-1: Seawater valve
Close the seawater valve.
Sample Picture
Fig. 6.14.1-2: Seawater pump
The seawater pump is located on the front side of the genset.
Sample Picture
Fig. 6.14.1-3: Cover Seawater Pump
Remove the cover of the seawater pump by loosen the 4 wing
screws from the housing.
Sample Picture
