General operation
Seite/Page 200 Panel Generator Control P6+ RE0703_Kunde_eng.R06.1 - Kapitel/Chapter 11: General operation 22.3.11
11.4.4.4 Configuration and setting sheet KE04
Standard jumpering for generators with DC-alternator.
Panel for 24V-operation (over attitude of solder jumper J101 alternatively 12V-operation is possible).
The safety device is installed with the value 0,63AT.
The circuit parts for 24V-operation are not equipped.
Fig. 11.4.4.4-1: Einstellung der Lötjumper für diese Konfiguration (Spalte Konf.)
The solder jumpers are marked on the printed circuit board (with jumper no. and at three-part solder jumper with soldering surface no.)
(1): Equivalent resistance for load control lamp e.g. for use with three-phase alternator also integrated automatic controller of Bosch. The resistance value is 68Ω 3W,
i.e. only for 12V.
(2): A closed contact switches the appropriate input to GND.
Jumper Status Konf. Description
J1 closed during operation of the start button heat is along-operated
closed X Function deactivated
J3 1-2 Dynamo excitation resistor 68R is switched on with Fuel-Pump (1)
2-3 Dynamo excitation resistor 68R is switched on with Panel-ON (1)
closed X Dynamo excitation resistor is deactivated
J101 closed 12V - operation
closed X 24V - operation
J201 1-2 X T-Engine-input, for contact, which opens in case of error (2)
2-3 T-Engine-input, for contact, which closes in case of error (2)
J202 1-2 Water leak-input / Replace air filter, for contact, which opens in case of error (2)
2-3 X Water leak-input / Replace air filter, for contact, which closes in case of error (2)
J203 1-2 X Oil-Press-input, for contact, which opens in case of error (2)
2-3 Oil-Press-input, for contact, which closes in case of error (2)
J204 1-2 X AC-Fault-input / Fuel level, for contact, which opens in case of error (2)
2-3 AC-Fault-input / Fuel level, for contact, which closes in case of error (2)
J205 1-2 X T-Winding-input, for contact, which opens in case of error (2)
2-3 T-Winding-input, for contact, which closes in case of error (2)
J206 1-2 X Input Water leak has red LED and switches off
2-3 Input Water leak has yellow LED and does not switch off
J207 1-2 X Input AC-Fault has red LED and switches off
2-3 Input AC-Fault has yellow LED and does not switch off
J208 1-2 X DC-Control-Signal (-) = OK dynamo 12V at Kubota Z 482 / D 722 engines
2-3 DC-Control-Signal (+) = OK three-phase DC-alternator
J209 1-2 X DC-Control-Signal (-) = OK dynamo 12V at Kubota Z 482 / D 722 engines
2-3 DC-Control-Signal (+) = OK three-phase DC-alternator
J210 closed Input AC-Fault has Pull-Up-current
≥
10mA
open X Input AC-Fault has Pull-Up-current
≥
2,5mA
