11.7.3 Terminal connections
Connection for the automatic adapter X2 (row with odd pin numbers // I/O viwe from operating panel)
Fig. 11.7.3-1: Terminal connections automatic adapter
Pin-no. Pin-name I / O Description
1 VBF O power supply + (operation voltage behind fuse)
3 GND O power supply - (ground)
5 VBFS O power supply + switched (voltage Pin 1, with panel switched on)
7 12V O power supply + switched, at 12V-operation over closed soldered jumper J101 connected with
VBFS (at optional 24V-operation: VBFS over internal voltage regulator at 12,9V regulated)
9 GND O power supply - (ground)
11 GND O power supply - (ground)
13 /Heat-signal I Heat is active, if the input is switched to GND
15 /Start-signal I Start is active, if the input is switched to GND
17 GND O power supply - (ground)
19 GND O power supply - (ground)
21 GND O power supply - (ground)
23 GND O power supply - (ground)
25 GND O power supply - (ground)
27 /Stop-signal I The Fuel pump signal is switched off, as long as the input is switched to GND, (also when star-
ting)
29 FP-Int O Fuel pump signal internally, decoupled over diode from external signal
31 /Fault-signal O Output is switched to GND, if an error is present (inputs 3, 4, 5, 11 and 12, if configured and ge-
nerally for 2s, after switching on the panel)
33 GND O power supply - (ground)
