5.9.4.1 Alternative Mini VCS
Alternative for generators without AC control box the Mini VCS.
The Mini VCS and the capacitators are is mounted at the generator.
Fig. 5.9.4.1-1: Mini VCS at the Panda 6000 ND PMSMini VCS at the Panda 6500 NE PMS
Fig. 5.9.4.1-2: Capacitors at the Panda 6000 ND PMSCapacitors at the Panda 6500 NE PMS
Note:
The Mini VCS has no internal fuse.
