3.3.2 Opening the MPL sound insulation capsule .
Fig. 3.3-1: Sound insulation capsule, side part To open the sound insulation capsule, the closures must
be rotated roughly 180° counter-clockwise. Use a fl at
head screwdriver. Pull the sidewalls out by gripping into
the slots.
Fig. 3.3.2-2: Closure locked Closure locked
Fig. 3.3-3: Closure open Closure open
3.3.3 Opening the GFK sound insulation capsule
