Fischer Panda 6500 PMS - Components of Combustion Air

The Panda Generator
Seite/Page 50 Panda_6500_7mini_PMS_eng.R01 - Kapitel/Chapter 4: The Panda Generator 22.3.11
Fig. 4.3.4-2: Fuel Connections Connecting point for the fuel pipes
1. Fuel intake
2. Fuel backflow
Fig. 4.3.4-3: Fuel Solenoid Valve Fuel solenoid valve
Fig. 4.3.4-4: Injection Nozzle Injection nozzles
4.3.5 Components of combustion air
1
2
