General operation
22.3.11 Panel Generator Control P6+ RE0703_Kunde_eng.R06.1 - Kapitel/Chapter 11: General operation Seite/Page 205
With (+) characterized connection is the input.
The input is connected through a resistance to 12V (with 24V-operated internally generated). If the two connections
are short circuited over a potential-free contact, then the input current flows.
To be considered for an electronic contact the low input current and the polarity is to be selected.
The high input current is to be selected for an electromechanical contact.
The input is debounced (delay time approx.1s).
On the input an external voltages must not be set.
Fig. 11.7.2-1: Data
Fig. 11.7.2-2: Settings
Attention:
The automatic adapter must only be used together with a
device. The starter should only be switched on when the gene-
rator stationary (shut-down)!
Data:
Parameter Information
Operation voltage The automatic adapter power is supplied via the generator control panel P6+. The
same absolute maximum ratings obtain as with the generator control panel P6+.
Operation temperature The same absolute maximum ratings obtain as with the generator control panel
P6+.
Proper power consumption 10mA - 20mA
Tolerance of times ± 10%
8-pole DIP-switch S1 settings (S1.1 to S1.8):
standard S1.1 S1.2 S1.3 S1.4 S1.5 S1.6 S1.7 S1.8
Heat-time 2,5s OFF OFF
5s ON OFF
10s X OFF ON
20s ON ON
Start-time 8s X OFF
16s ON
Stop-time 16s OFF OFF
32s X ON OFF
64s OFF ON
128s ON ON
Operation-mode Normal X OFF
Test (all times over 16) ON
Input current 1,25mA OFF
7mA X ON
