The Panda Generator
22.3.11 Panda_6500_7mini_PMS_eng.R01 - Kapitel/Chapter 4: The Panda Generator Seite/Page 53
Fig. 4.3.6-3: Load Main power
At the front of the sound insulation cover is also the outlet for
the main power cable.
Fig. 4.3.6-4: Electrical connections Electrical connections for control / fuel pump
1. Remote control panel
2. Fuel pump
Fig. 4.3.6-5: Starter motor Starter motor
1. Starter motor and
2. Solenoid switch
The diesel engine is started electrically.
The electrical starter with the solenoid switch is located on
the right side of the generator, in front of the engine.
1
1
2
1
2
