The Panda Generator
Seite/Page 48 Panda_6500_7mini_PMS_eng.R01 - Kapitel/Chapter 4: The Panda Generator 22.3.11
Fig. 4.3.3-2: Heat exchanger Heat exchanger
The heat exchanger separates the raw water system from
the fresh water system, so that the generator components do
not have contact with the raw water circulation system.
Fig. 4.3.3-3: Cooling Water Connection Block Cooling Water Connection Block
Fig. 4.3.3-4: Internal Fresh Water Cooling Pump Internal Fresh Water Cooling pump
The fresh water pump aids the ciculation of the fresh
water.
The fresh water enters and leaves the engine at the fresh
water pump.
