The Panda Generator
Seite/Page 56 Panda_6500_7mini_PMS_eng.R01 - Kapitel/Chapter 4: The Panda Generator 22.3.11
Fig. 4.3.8-1: Engine oil filler neck
Oil filler neck with cap
Normally the filler neck for the engine oil is on the top side of
the valve cover.
Fig. 4.3.8-2: Engine oil dipstick
Oil dipstick
At the dipstick the permissible level is indicated by the mar-
kings "maximum" and "minimum".
Fig. 4.3.8-3: Engine oil filter
Engine oil filter
This oil filter should also be replaed, when an oil change is
carried out.
