Installation Instructions
22.3.11 Panda PMS 8.000 NE - 42 NE Manual.R05 - Kapitel/Chapter 5: Installation Instructions Seite/Page 73
Fig. 5.6.5.1-1: Volume of the exhaust water collector
If there are any doubts, a verifiction can easily be made by temporarily using a clear-sighted hose as exhaust hose.
In that way, the coolant level can be checked very easily.
Fig. 5.6.5.1-2: Testing the coolant level
