● Oil drain screw or oil drain valve for changing the oil
● Air filter or wet-air filter for ventilation and bleeding
Further information
Additional information and a detailed illustrated description of the gear unit can be found in the
dimension drawing provided in the complete gear unit documentation.
Gear unit equipment
The diagram below shows the gear unit equipment on type H2SH 24 (SOND 622) units:
① Cover ⑥ Alignment surfaces
② Inspection and assembly cover ⑦ Lifting eyes
③ Housing ⑧ Gear unit fastening
④ Rating plate ⑨ Shaft seal
⑤ Cover ⑩ Alignment thread
Figure 3-1 Gear unit equipment for type H2SH 24 (SOND 622) gear units
The diagram below shows the gear unit equipment for type M1S x 315 gear units:
Description
3.3 Housing
Gear unit 5118en
22 Operating Instructions 10/2017
