① Rating plate ⑥ Sling swivels
② Inspection and assembly cover ⑦ Alignment surfaces
③ Cover ⑧ Shaft seal
④ Housing ⑨ Alignment thread
⑤ Cover ⑩ Gear unit fastening
Figure 3-3 Gear unit equipment for type H3SX gear units
Further information
Additional information and a detailed illustrated description of the gear unit can be found in the
dimension drawing provided in the complete gear unit documentation.
3.4 Oil supply to the gear unit
Introduction
The oil supply to the various gear unit components can be implemented using the following oil
supply variants:
● Splash lubrication
● Pressure lubrication
● Combination of both oil supply variants
Description
3.4 Oil supply to the gear unit
Gear unit 5118en
24 Operating Instructions 10/2017
