FLENDER H2SH 24 - Figure 3-2 Gear Unit Equipment for Type M1 S X 315 Gear Units








① Rating plate ⑥ Gear unit fastening
② Lifting eyes ⑦ Shaft seal
③ Cover ⑧ Alignment surfaces
④ Cover ⑨ Inspection and assembly cover
⑤ Housing
Figure 3-2 Gear unit equipment for type M1S X 315 gear units
The diagram below shows the gear unit equipment for type H3SX gear units:
Description
3.3 Housing
Gear unit 5118en
Operating Instructions 10/2017 23
