① Adhesive tape ③ Labyrinth, filled with grease, can be regreased
② Air gap ④ Labyrinth seal
Figure 4-9 Preservation of gear units with Tacolab seals
Do not remove the adhesive tape until you are ready to commission the unit.
Application planning
4.4 Special aspects of gear unit lubrication and preservation
Gear unit 5118en
54 Operating Instructions 10/2017
