13 Data logger and transmission of data FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 127
13.2.4 Transmission parameters
• the transmitter sends CRLF-terminated ASCII
• max. line length: 255 digits
RS232
• default: 9 600 bits/s, 8 data bits, even parity, 2 stop bits, protocol RTS/CTS (hardware, handshake)
The transmission parameters of the RS232 interface can be changed:
RS485
• default: 9 600 bits/s, 8 data bits, even parity, 1 stop bit
The transmission parameters of the RS485 interface can be changed in the program branch Special Funct.\SYSTEM
settings\Network. This display will only be indicated if the transmitter has an RS485 interface.
13.2.5 Online transmission of data to a terminal program
• Start the terminal program.
• Enter the transmission parameters into the terminal program (see section 13.2.4). The transmission parameters of the
terminal program and the transmitter have to be identical.
Transmitter settings
• Select the program branch Output Options. Press ENTER.
• Select the channel for which the online transmission of data is to be activated. Press ENTER until the menu item Serial
Output is displayed.
• Set the storage rate (see section 13.1.2).
• Start the measurement. The measuring point number will be requested (see section 13.1.4).
Enter HotCode 232-0- (see section 9.5).
Set the transmission parameters in the 4 scroll lists. Press ENTER.
• baud: baud rate
• data: number of data bits
• par: parity
• st: number of stop bits
Select Special Funct.\SYSTEM settings\Network to change the settings of the
transmission parameters.
Press ENTER to confirm the address of the measuring instrument in the network.
Select default to display the default transmission parameters.
Select setup to change the transmission parameters. Press ENTER.
Set the transmission parameters in the 3 scroll lists. Press ENTER.
• baud: baud rate
• parity: parity
• st: number of stop bits
The default transmission parameters will be set if default is selected and the transmis-
sion parameters have not been changed.
Select yes to activate the online transmission of data. Press ENTER.
The measured values are transmitted during the measurement.
baud<data par st
9600 8bit EVEN 2
SYSTEM settings↕
Network
Device address:
0 ADR
RS485 protocol
default >SETUP<
>baud< parity st
9600 EVEN 1
Serial Output
no >YES<
SEND ONLINE-HEAD
20 mm
