FLUXUS F808, F809 A Menu structure
170 UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23
SYSTEM settings\Measuring
selection of the displays for the settings of the measurement
activation of the WaveInjector (optional) x
enabling of the NoiseTrek mode x
selection if the toggling between the TransitTime and the NoiseTrek mode has
to be carried out manually or automatically
This display will only be indicated if the NoiseTrek mode is enabled.
x
input of the time after which the transmitter has to toggle to the NoiseTrek mode
if there are no valid measured values in the TransitTime mode
range: 0...9999 s
0: no toggling to the NoiseTrek mode
This display will only be indicated if the automatic toggling between the
TransitTime and the NoiseTrek mode is activated.
x
input of the time after which the transmitter has to toggle to the TransitTime
mode if there are no valid measured values in the NoiseTrek mode
range: 0...9999 s
0: no toggling to the TransitTime mode
This display will only be indicated if the automatic toggling between the
TransitTime and the NoiseTrek mode is activated.
x
input of the time after which the transmitter has to toggle to the TransitTime
mode
range: 0...9999 s
0: no toggling to the TranitTime mode
This display will only be indicated if the automatic toggling between the
TransitTime and the NoiseTrek mode is activated.
x
input of the time after which the transmitter has to toggle to the NoiseTrek mode
if there are no valid measured values in the TransitTime mode
range: 0...9999 s
This display will only be indicated if the automatic toggling between the
TransitTime and the NoiseTrek mode is activated.
x
activation of the display for the difference between the measured and the ex-
pected sound speed of a selected reference fluid during the measurement
x
selection whether the flow velocity is displayed and transmitted with or without
profile correction
x
input of an upper limit of the flow velocity
range: 0.1...25.5 m/s
0 m/s: no detection for outliers
All measured values that are greater than the limit will be marked as outliers.
x
selection of the input of a lower limit for the flow velocity:
• absolut: independent of the flow direction
• sign: dependent on the flow direction
x
INIT-
resistant
SYSTEM settings↕
Measuring
WaveInjector
off >ON<
Enable NoiseTrek
off >ON<
Auto NoiseTrek ?
no >YES<
TT-Failed |After
NoiseTrek | 40s
NT-Failed |After
TransTime | 60s
NT-Ok,but | Each
check TT | 300s
Keep TT | For
checking | 5s
Compare c-fluid
no >YES<
Flow Velocity
normal >UNCORR.<
Velocity limit
0.0 m/s
Cut-off Flow
absolut >SIGN<
