Flexim FLUXUS F808 A1 Series User Manual

7 Installation of FLUXUS F809 FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 73
frequency output
(open collector)
F809**-A1
F809**-F1
F1: 2 (+)
F1: 1 (-)
U
ext
= 5...30 V
R
c
[kΩ] = U
ext
/I
c
[mA]
I
c
= 2...100 mA
I
off
≤ 0.4 mA
frequency output
(open collector)
NAMUR
F809**-A1
F809**-F1
F1: 2 (+)
F1: 1 (-)
U
ext
= 8.2 V
R
c
= 1 kΩ
DIN EN 60947-5-6 (NAMUR)
frequency output
(open collector)
F809**-A1
F809**-F1
F1: 2 (+)
F1: 1 (-)
U
ext
= 5...24 V
R
c
[kΩ] = U
ext
/I
c
[mA]
I
c
= 1...4 mA
binary output
(open collector)
F809**-A1
F809**-F1
B1...B4: 6/8 (+)
B1...B4: 5/7 (-)
U
ext
= 5...24 V
R
c
[kΩ] = U
ext
/I
c
[mA]
I
c
= 1...4 mA
binary output
(open collector)
F809**-A1
F809**-F1
B1/B2: 6/8 (+)
B1/B2: 5/7 (-)
U
ext
= 5...30 V
R
c
[kΩ] = U
ext
/I
c
[mA]
I
c
= 2...100 mA
I
off
≤ 0.4 mA
binary output
(open collector)
NAMUR
F809**-A1
F809**-F1
B1/B2: 6/8 (+)
B1/B2: 5/7 (-)
U
ext
= 8.2 V
R
c
= 1 kΩ
DIN EN 60947-5-6 (NAMUR)
binary output
(Reed relay)
F809**-A1
F809**-F1
B3/B4: 10
B3/B4: 9
U
max
= 48 V
I
max
= 100 mA
Tab. 7.14: Circuits of the outputs
output transmitter external circuit remark
internal circuit connection
The number, type and connections of the outputs are customized.
R
ext
is the sum of all ohmic resistances in the circuit (e.g. resistance of the conductors, resistance of the amperemeter/voltmeter).
R
c
U
ext
V
+
-
R
c
U
ext
V
mA
+
-
R
c
U
ext
V
+
-
R
c
U
ext
V
+
-
R
c
U
ext
V
+
-
R
c
U
ext
V
+
-
a
b
