8 Installation of the Transducers FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 97
Fig. 8.54: PermaFiX on the pipe (example: diagonal arrangement with bolts)
Fig. 8.55: PermaFiX on the pipe (example: reflection arrangement with tension straps)
PermaFiX
bolts
flexible conduit
(approved for FM Class I,
Division 1)
conduit sealing
fitting
PermaFiX
tension straps
flexible conduit
(approved for FM Class I,
Division 1)
conduit sealing
fitting
