Configuration of the outputs
(see chapter 14)
Options [4] Special functions
Channel x
Outputs
Outputs
Active Passive
 Current
 Voltage
 Frequency
 Binary
… Enable
No Yes
Source item
[1] [1] [1] [2]
Sound speed Flow quantities Totalizers Fluid properties Diagnostic
values
Miscellaneous Event trigger Pulse
Pulse value
Status Values
 R1
 R2
 R3
 R4
Pulse width
Output range Output range Error value
Status OK Error value
Measured
values
[3]
Measured
values
[3]
Absolute
value
Sign
Absolute
value
Sign
Start of meas.
range
Start of meas.
range
Start of meas.
range
Idle state End of meas.
range
End of meas.
range
Output info Output info
Output info Output info Test signal Test signal
Test signal Test signal Test mea. range Test mea. range
Test mea. range
Legend
[1] not available with calculation channels
[2] only available for binary outputs supporting pulse outputs
[3] request only if physical quantity can adopt a negative value
[4] only if switchable current outputs are available
