FT-111(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 137 of 146
10100
20
Not used
10101
21
SetPoint-1 Low
Only available for Threshold and
Window feature.
Refer to sub-block 36-, page 59
to see the availabilities.
10110
22
SetPoint-2 Low
10111
23
SetPoint-3 Low
11000
24
SetPoint-4 Low
11001
25
SetPoint-5 Low
11010
11110
26
30
Not used
11111
31
Use the Expanded Command list
( Refer to Table 12-3 )
B37 ... B33
Read Data
Selection
00000
0
Actual weight ( Net if the indication is in Net )
00001
1
Gross weight
00010
2
Tare weight
00011
3
ALL Status ( Refer to Table 12-1 )
00100
4
Calibration Status ( Refer to Table 12-2 )
00101
5
Last print value
00110
01010
6
10
Not used
01011
11
CN (Label number)
01100
01110
12
14
Not used
01111
15
Set Point-1 (High)
10000
16
Set Point-2 (High)
10001
17
Set Point-3 (High)
10010
18
Set Point-4 (High)
10011
19
Set Point-5 (High)
10100
20
Not used
10101
21
SetPoint-1 Low
Only available for Threshold and
Window feature.
Refer to sub-block 36-, page 59
to see the availabilities.
10110
22
SetPoint-2 Low
10111
23
SetPoint-3 Low
11000
24
SetPoint-4 Low
11001
25
SetPoint-5 Low
11010
11110
26
30
Not used
11111
31
Use the Expanded Command list
( Refer to Table 12-3 )
B32
New CMD
Toggle
Apply commands which are listed in this table.
B31-B0
B37-B33 bits defines the usage of this Dword.
(1) Write this command after writing values to Low Dword of RxPDO then apply this command with New CMD.
