Fluidigm CyTOF XT - CyTOF XT Site Requirement Specifications; CyTOF XT Specification

Chapter 1: Product Overview
CyTOF XT Site Requirement Specifications
8 CyTOF XT User Guide
CyTOF XT Site Requirement Specifications
Dimensions
Width
(cm/in)
Height (cm/in)
Depth (cm/in)
Weight (kg/lb)
CyTOF XT
instrument
93/37
135/53
75/30
288/635
Electrical*
Maximum
Power
Draw
(VA)
Operating Voltage
(V AC)
Operating
Frequency
(Hz)
Maximum Continuous
Current (A)
CyTOF XT instrument
4,000
200240
50/60
20
Environmental
Operating T (°C)
Humidity (%)
CyTOF XT instrument
1825
2080
non-condensing
Gas
Ultrahigh Purity Argon

Flow Rate
(L/min)
CyTOF XT instrument
85 ±5 psi (100 psi max.)
15
Vent
Hose Diameter. (mm/in)
Flow Rate
cfm/(L/sec)
Anemometer
(m/sec)/(ft/min)
Vented Outside Lab
Power kW/(BTU/hr)
Torch Box
100/4
75 ±15/35 ±7
5/917
-
System
-
-
-
3.6/12276
* One dedicated electrical branch circuit (single-phase, 30 A single-phase 200240 V AC, 50/60 Hz) is used to
provide power to the CyTOF XT instrument.
 For optimal performance the temperature should be 20 ±2 °C.
CyTOF XT Specification
Instrument Specifications
Description
Specification (instrument)
Channels
135
Mass range
75209 amu
Abundance sensitivity
<0.3% for M+1 with M=159Tb
<0.3% for M-1 with M=175Lu
Instrument response
500 dual counts of 159Tb+ per

Dynamic range
4.5 orders of magnitude
Calibration
Automated
Operating system
Windows® 10 Enterprise LTSC
Sample introduction
Dual syringe drive
Maximum sustained event rate
500 events per sec
Flow rate
30 L/min
