Fluke 5730A User Manual

Introduction and Specification
Electrical Specifications 1
1-15
Range Resolution
Frequency
(Hz)
Absolute / ±5 °C from calibration temperature Relative ±1 °C
24 Hours 90 Days 180 Days 1 Year 24 Hours 90 Days
±(ppm output + μV)
22 V
10 μV
10 - 20
20 - 40
40 - 20 k
20 k - 50 k
50 k - 100 k
100 k - 300 k
300 k - 500 k
500 k - 1 M
250 + 500
95 + 200
45 + 70
75 + 120
95 + 250
285 + 800
1000 + 2500
1500 + 4000
270 + 500
100 + 200
46 + 70
77 + 120
97 + 250
290 + 800
1100 + 2500
1600 + 4000
290 + 500
105 + 200
47 + 70
78 + 120
98 + 250
295 + 800
1150 + 2500
1700 + 4000
300 + 500
110 + 200
48 + 70
80 + 120
100 + 250
300 + 800
1200 + 2500
1800 + 4000
250 + 500
95 + 200
30 + 70
70 + 120
100 + 250
270 + 800
900 + 2500
1300 + 4000
270 + 500
100 + 200
40 + 70
75 + 120
105 + 250
290 + 800
1000 + 2500
1400 + 4000
±(ppm output + mV)
220 V
[2]
100 μV
10 - 20
20 - 40
40 - 20 k
20 k - 50 k
50 k - 100 k
100 k - 300 k
300 k - 500 k
500 k - 1 M
250 + 5
95 + 2
57 + 0.7
90 + 1.2
160 + 3
900 + 20
5000 + 50
8000 + 100
270 + 5
100 + 2
60 + 0.7
95 + 1.2
170 + 3
1000 + 20
5200 + 50
9000 + 100
290 + 5
105 + 2
62 + 0.7
97 + 1.2
175 + 3
1050 + 20
5300 + 50
9500 + 100
300 + 5
110 + 2
65 + 0.7
100 + 1.2
180 + 3
1100 + 20
5400 + 50
10,000 + 100
250 + 5
95 + 2
45 + 0.7
75 + 1.2
140 + 3
600 + 20
4500 + 50
8000 + 100
270 + 5
100 + 2
50 + 0.7
80 + 1.2
150 + 3
700 + 20
4700 + 50
8500 + 100
1100 V
[1]
1 mV
15 - 50
50 - 1 k
300 + 20
70 + 4
320 + 20
75 + 4
340 + 20
80 + 4
360 + 20
85 + 4
300 + 20
50 + 4
320 + 20
55 + 4
5725A Amplifier:
1100 V
1 mV
40 - 1 k
1 k - 20 k
20 k - 30 k
75 + 4
105 + 6
230 + 11
80 + 4
125 + 6
360 + 11
85 + 4
135 + 6
440 + 11
90 + 4
165 + 6
600 + 11
50 + 4
85 + 6
160 + 11
55 + 4
105 + 6
320 + 11
750 V
30 k - 50 k
50 k - 100 k
230 + 11
600 + 45
360 + 11
1300 + 45
440 + 11
1600 + 45
600 + 11
2300 + 45
160 + 11
380 + 45
320 + 11
1200 + 45
Notes:
1. Maximum output 250 V from 15-50 Hz.
2. See Volt-Hertz capability in Figure A.
5730A AC Voltage Specifications: 95 % Confidence Level
Range Resolution
Frequency
(Hz)
Absolute / ±5 °C from calibration temperature Relative ±1 °C
24 Hours 90 Days 180 Days 1 Year 24 Hours 90 Days
±(ppm output + μV)
2.2 mV 1 nV
10 - 20
20 - 40
40 - 20 k
20 k - 50 k
50 k - 100 k
100 k - 300 k
300 k - 500 k
500 k - 1 M
200 + 4
80 + 4
70 + 4
170 + 4
400 + 5
800 + 10
1100 + 20
2400 + 20
220 + 4
85 + 4
75 + 4
180 + 4
460 + 5
900 + 10
1200 + 20
2500 + 20
230 + 4
87 + 4
77 + 4
190 + 4
480 + 5
1000 + 10
1300 + 20
2600 + 20
240 + 4
90 + 4
80 + 4
200 + 4
500 + 5
1050 + 10
1400 + 20
2700 + 20
200 + 4
80 + 4
50 + 4
70 + 4
160 + 5
280 + 10
650 + 20
2100 + 20
220 + 4
85 + 4
55 + 4
80 + 4
180 + 5
320 + 10
800 + 20
2400 + 20
22 mV 10 nV
10 - 20
20 - 40
40 - 20 k
20 k - 50 k
50 k - 100 k
100 k - 300 k
300 k - 500 k
500 k - 1 M
200 + 4
80 + 4
70 + 4
170 + 4
400 + 5
800 + 10
1100 + 20
2400 + 20
220 + 4
85 + 4
75 + 4
180 + 4
460 + 5
900 + 10
1200 + 20
2500 + 20
230 + 4
87 + 4
77 + 4
190 + 4
480 + 5
1000 + 10
1300 + 20
2600 + 20
240 + 4
90 + 4
80 + 4
200 + 4
500 + 5
1050 + 10
1400 + 20
2700 + 20
200 + 4
80 + 4
50 + 4
70 + 4
160 + 5
280 + 10
650 + 20
2100 + 20
220 + 4
85 + 4
55 + 4
80 + 4
180 + 5
320 + 10
800 + 20
2400 + 20
220 mV 100 nV
10 - 20
20 - 40
40 - 20 k
20 k - 50 k
50 k - 100 k
100 k - 300 k
300 k - 500 k
500 k - 1 M
200 + 12
80 + 7
54 + 7
105 + 7
296 + 17
535 + 20
1100 + 25
2400 + 45
220 + 12
85 + 7
55 + 7
110 + 7
298 + 17
583 + 20
1200 +25
2500 + 45
230 + 12
87 + 7
56 + 7
115 + 7
303 + 17
600 + 20
1300 + 25
2600 + 45
240 + 12
90 + 7
57 + 7
120 + 7
310 + 17
655 + 20
1400 + 25
2700 + 45
200 + 12
80 + 7
50 + 7
70 + 7
160 + 17
280 + 20
650 + 25
2100 + 45
220 + 12
85 + 7
55 + 7
80 + 7
180 + 17
320 + 20
800 + 25
2400 + 45

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
