The triaxial orientation graphic ( ) shows how the
sensor axes are related to the selected measure dir-
ection.
The triaxial sensor measure axes icon ( ) gives more
help on how the sensor is mounted.
Tap ( ) to close the sensor information panel ( ).
In this example, the triaxial sensor VIB 6.655 is mounted
vertically on the machine, and the related measure dir-
ections are shown on the sensor ( ).
The sensor is connected to channel 1 ( ) on
VIBXPERT
3.
For evaluation in this example, the X-axis is horizontal,
Y-axis is axial and Z-axis is vertical.
