Locking assembly Shaft end
diameter,
mm
Sequence for tightening or loosening bolts
84 59 12 70
1
13
5
9
3
12
8
2
10
6
14
4
11
7
84 59 13 75
84 59 14 90
84 59 17
C3351, C3531, C3602 with drive units
905–960
110
1
9
5
13
3
12
8
16
2
10
6
14
4
11
7
15
84 60 11
C3351, C3531, C3602 with drive units
965–995; and C3800
110
1
5
9
3
8
12
2
6
10
4
7
11
Tightening torques
The table below gives the torque which should be used in each stage of the bolt-tightening process.
